NT1 Specifications |
|
| Output Connection | 3 Pin XLR. Balanced output between pin 2 (+), pin 3 (-) and pin 1 (ground) |
| Acoustic Principle | Pressure gradient |
| Active Electronics | JFET impedance converter with bipolar output buffer |
| Directional Pattern | Cardioid |
| Frequency Range | 20Hz ~ 20kHz |
| Output Impendence | 100Ω |
| Equivalent Noise | 4.5 dBA SPL (as per IEC651) |
| Maximum Output | +8 dBu (1kHz, 1% THD into 1K Ω load) |
| Sensitivity | -29 dB re 1V/Pa (35mV @ 94dB SPL) ± 2dB @ 1kHz |
| Dynamic Range | 128 dB SPL |
| Maximum SPL | 132 dB SPL |
| Signal-to-Noise Ratio | 90 dBA SPL (as per IEC651) |
| Power Requirements | 24V phantom power 48V phantom power |
| Net Weight (grams) | 395 |
| Colour | Black |
AI-1 Specifications |
|
| Computer Connectivity | USB |
| Form Factor | Desktop |
| Simultaneous I/O | 1 x 2 |
| Number of Preamps | 1 |
| Bit Depth | 24-bit |
| Sample Rates | 44.1 kHz 48 kHz 88.2 kHz 96kHz |
| Analog Inputs | 1 x Neutrik XLR-1/4” combo |
| Analog Outputs | 2 x 1/4” (impedance balanced) 1 x 1/4” (headphones) |
| Direct Monitor | Yes |
| USB | 1 x USB Type C |
| Bus Powered | Yes |
| OS Requirements | Mac OS 10.10 or later Windows 7 or later |
| Power | USB bus-powered |
| Net Weight (grams) 560 | 560 |
| Height x Width x Depth (millimetres) | 38 x 124 x 100 |
